Elevator Air Conditioner

Features:

1. The inner parts are made of galvanized plate, corrosion resistance, lifetime is about 10 years.

2. Adopt famous compressor, waterproof PCB, hydrophilic aluminum fin, internal thread tube.

3. The functions include cooling, heating, ventilation, dehumidification, timing on/off, auto-restart.

4. Adopt spraying & evaporation technology, the condensed water can evaporate automatically.

5. Use wireless remote control, automatic fault diagnosis.

6. Current overload protector for compressor, motor and other electrical parts.

7. Ceramic PTC heater with overheat protection device (Optional).

Model			KC(R)-18/DT-A
Power supply			220V-240V/50HZ/1PH
Refrigerant			R410A
Nominal capacity	Cooling	W	1800
Nominal capacity	Heating	W	1200
Rated input power	Cooling	W	620
Rated input power	Heating	W	1200
Rated current	Cooling	A	3.0
Rated current	Heating	A	5.3
Air circulation		M³/h	220
Noise in lift car		db(A)	≤45
Elevator air conditioner noise		db(A)	≤50
Waterproof grade			IPX4
Electric shock proof protection grade			I
Compressor protection			Overheat protection, over current protection, delay startup protection
Control method			Wire control + remote control
Machine dimension	Net	mm	430×400×300
Machine weight	Net	kg	19
Accessory packing dimension		mm	850280250
Accessory gross weight		kg	6
